Pin terminal, 6x16mm2, 63A
enlarge picture
| SKU | MAD6016E21 |
|---|---|
| EAN | 4744397018540 |
| Color | Natural |
| Wire material | Cu |
| Cross-section min. (mm²) | 1,5 |
| Cross-section max. (mm²) | 16 |
| Input wire min. (mm²) | 1,5 |
| Input wire max. (mm²) | 16 |
| Number of connections | 6 |
| Nominal current (A) | 80 |
| Nominal voltage (V) | 690 |
| Material | Brass |
| Mounting method | Device |
| Item width (mm) | 16 |
| Item length (mm) | 33 |
| Item height (mm) | 16 |
| Item weight (g) | 18 |
| Tightening torque (Nm) | 2,5 Nm |
| IP rating | IP00 |
| CN8 code | 85369010 |
| Package quantity (pcs) | 100 |
